Edge-Core ES4625 - Figure 3-59 LACP - Port Internal Information

Configuring the Switch
3-102
3
Web – Click Port, LACP, Port Internal Information. Select a port channel to display
the corresponding information.
Figure 3-59 LACP - Port Internal Information
CLI – The following example displays the LACP configuration settings and
operational state for the local side of port channel 1.
Console#show lacp 1 internal 4-163
Port channel: 1
-------------------------------------------------------------------------
Oper Key: 3
Admin Key: 0
Eth 1/ 2
-------------------------------------------------------------------------
LACPDUs Internal: 30 sec
LACP System Priority: 32768
LACP Port Priority: 32768
Admin Key: 3
Oper Key: 3
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
