Edge-Core ES4625 - Displaying Local ARP Entries; Figure 3-123 ARP Other Addresses

Configuring the Switch
3-214
3
CLI - This example shows all entries in the ARP cache.
Displaying Local ARP Entries
The ARP cache also contains entries for local interfaces, including subnet, host, and
broadcast addresses.
Command Attributes
• IP Address – IP address of a local entry in the cache.
• MAC Address – MAC address mapped to the corresponding IP address.
• Interface – VLAN interface associated with the address entry.
• Entry Count – The number of local entries in the ARP cache.
Web - Click IP, ARP, Other Addresses.
Figure 3-123 ARP Other Addresses
Console#show arp 4-247
Arp cache timeout: 1200 (seconds)
IP Address MAC Address Type Interface
--------------- ----------------- --------- -----------
10.1.0.0 ff-ff-ff-ff-ff-ff other 1
10.1.0.11 00-11-22-33-44-55 static 1
10.1.0.12 01-02-03-04-05-06 static 1
10.1.0.19 00-10-b5-62-03-74 dynamic 1
10.1.0.253 00-00-ab-cd-00-00 other 1
10.1.0.255 ff-ff-ff-ff-ff-ff other 1
Total entry : 6
Console#clear arp-cache 4-247
This operation will delete all the dynamic entries in ARP Cache.
Are you sure to continue this operation (y/n)?y
Console#
