Edge-Core ES4625 - Figure 3-103 IGMP Interface Settings

Multicast Filtering
3-179
3
Web – Click IP, IGMP, Interface Settings. Specify each interface that will support
IGMP (Layer 3), specify the IGMP parameters for each interface, then click Apply.
Figure 3-103 IGMP Interface Settings
CLI – This example configures the IGMP parameters for VLAN 1.
Console(config)#interface vlan 1 4-190
Console(config-if)#ip igmp 4-235
Console(config-if)#ip igmp last-memb-query-interval 10 4-237
Console(config-if)#ip igmp max-resp-interval 20 4-237
Console(config-if)#ip igmp query-interval 100 4-237
Console(config-if)#ip igmp robustval 3 4-235
Console(config-if)#ip igmp version 1 4-238
Console(config-if)#end
Console#show ip igmp interface vlan 1 4-239
Vlan 1 is up
IGMP is enable, version is 2
Robustness variable is 2
Query interval is 125 sec
Query Max Response Time is 10 sec, Last Member Query Interval is 1 sec
Querier is 10.1.0.253
Console#
