Configuring the Switch
3-72
3
Displaying 802.1X Statistics
This switch can display statistics for dot1x protocol exchanges for any port.
Table 3-7 802.1X Statistics
Parameter Description
Rx EAPOL Start The number of EAPOL Start frames that have been received by this Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been received by this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received by this Authenticator in
which the frame type is not recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that have been received by this
Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received by this Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id frames) that have
been received by this Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received by this Authenticator in
which the Packet Body Length field is invalid.
Rx Last EAPOLVer The protocol version number carried in the most recently received EAPOL frame.
Rx Last EAPOLSrc The source MAC address carried in the most recently received EAPOL frame.
Tx EAPOL Total The number of EAPOL frames of any type that have been transmitted by this
Authenticator.
Tx EAP Req/Id The number of EAP Req/Id frames that have been transmitted by this Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id frames) that have been
transmitted by this Authenticator.
