Configuring the Switch
3-92
3
Web – Click Port, Port Configuration or Trunk Configuration. Modify the required
interface settings, and click Apply.
Figure 3-54 Port - Port Configuration
CLI – Select the interface, and then enter the required settings.
Console(config)#interface ethernet 1/13 4-143
Console(config-if)#description RD SW#13 4-144
Console(config-if)#shutdown 4-148
.
Console(config-if)#no shutdown
Console(config-if)#no negotiation 4-145
Console(config-if)#speed-duplex 100half 4-144
.
Console(config-if)#negotiation
Console(config-if)#capabilities 100half 4-146
Console(config-if)#capabilities 100full
Console(config-if)#exit
Console(config)#interface ethernet 1/21
Console(config-if)#media-type copper-forced 4-148
Console(config-if)#
