Edge-Core ES4625 - Figure 3-135 OSPF General Configuration

IP Routing
3-237
3
Web - Click Routing Protocol, OSPF, General Configuration. Enable OSPF, specify
the Router ID, configure the other global parameters as required, and click Apply.
Figure 3-135 OSPF General Configuration
CLI - This example configures the router with the same settings as shown in the
screen capture for the web interface.
Console(config)#router ospf 4-265
Console(config-router)#router-id 10.1.1.253 4-265
Console(config-router)#no compatible rfc1583 4-266
Console(config-router)#default-information originate always
metric 10 metric-type 2 4-267
Console(config-router)#timers spf 10 4-268
Console(config-router)#
