Spanning Tree Commands
4-185
4
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• This command defines the priority for the use of an interface in the multiple
spanning-tree. If the path cost for all interfaces on a switch are the same, the
interface with the highest priority (that is, lowest value) will be configured as
an active link in the spanning tree.
• Where more than one interface is assigned the highest priority, the interface
with lowest numeric identifier will be enabled.
Example
Related Commands
spanning-tree mst cost (4-183)
spanning-tree protocol-migration
This command re-checks the appropriate BPDU format to send on the selected
interface.
Syntax
spanning-tree protocol-migration interface
interface
• ethernet unit/port
- unit - Stack unit. (Range: 1-8)
- port - Port number. (Range: 1-25/49)
• port-channel channel-id (Range: 1-32)
Command Mode
Privileged Exec
Command Usage
If at any time the switch detects STP BPDUs, including Configuration or
Topology Change Notification BPDUs, it will automatically set the selected
interface to forced STP-compatible mode. However, you can also use the
spanning-tree protocol-migration command at any time to manually
re-check the appropriate BPDU format to send on the selected interfaces (i.e.,
RSTP or STP-compatible).
Example
Console(config)#interface ethernet ethernet 1/5
Console(config-if)#spanning-tree mst 1 port-priority 0
Console(config-if)#
Console#spanning-tree protocol-migration eth 1/5
Console#
