Spanning Tree Algorithm Configuration
3-131
3
CLI – This example sets the priority for MSTI 1, and adds VLANs 1-5 to this MSTI.
---------------------------------------------------------------
Eth 1/ 7 information
---------------------------------------------------------------
Admin status: enabled
Role: master
State: forwarding
External admin path cost: 10000
Internal admin path cost: 10000
External oper path cost: 10000
Internal oper path cost: 10000
Priority: 128
Designated cost: 0
Designated port: 128.1
Designated root: 32768.1.0030F1D473A0
Designated bridge: 32768.1.0030F1D473A0
Fast forwarding: disabled
Forward transitions: 1
Admin edge port: disabled
Oper edge port: disabled
Admin Link type: auto
Oper Link type: point-to-point
Spanning Tree Status: enabled
.
.
.
Console(config)#spanning-tree mst-configuration 4-176
Console(config-mst)#mst 1 priority 4096 4-177
Console(config-mstp)#mst 1 vlan 1-5 4-176
Console(config-mst)#
