Quality of Service
3-163
3
Command Attributes
Class Map
• Modify Name and Description – Configures the name and a brief description of
a class map. (Range: 1-32 characters for the name; 1-256 characters for the
description)
• Edit Rules – Opens the “Match Class Settings” page for the selected class entry.
Modify the criteria used to classify ingress traffic on this page.
• Add Class – Opens the “Class Configuration” page. Enter a class name and
description on this page, and click Add to open the “Match Class Settings” page.
Enter the criteria used to classify ingress traffic on this page.
• Remove Class – Removes the selected class.
Class Configuration
• Class Name – Name of the class map. (Range: 1-32 characters)
• Type – Only one match command is permitted per class map, so the match-any
field refers to the criteria specified by the lone match command.
• Description – A brief description of a class map. (Range: 1-256 characters)
• Add – Adds the specified class.
• Back – Returns to previous page with making any changes.
Match Class Settings
• Class Name – List of class maps.
• ACL List – Name of an access control list. Any type of ACL can be specified,
including standard or extended IP ACLs and MAC ACLs. (Range: 1-16 characters)
• IP DSCP – A DSCP value. (Range: 0-63)
• IP Precedence – An IP Precedence value. (Range: 0-7)
• VLAN – A VLAN. (Range:1-4093)
• Add – Adds the specified criteria to the class. Only one entry is permitted per class.
• Remove – Deletes the selected criteria from the class.
