Edwards STP-iXA2205 Series User Manual

STP-iXA2205 Series Turbomolecular Pump
Nov. 10 15 Issue 1-h
TECHNICAL DATA
2
2.4 Control unit
The values shown below are typical. They are not guaranteed.
Item STP-iXA2205 series
Input voltage DCV 96 ± 2
Input power A 10 maximum
Pollution degree 2
Installation category
㸈
Motor driving system 3-phase d.c. brushless motor driver
Output voltage under normal operation Hz 450 maximum
Panel indication LED POWER (Green LED)
FAILURE (Red/Orange LED)
ROTATION (Green/Orange LED)
Data
䋨Green LED䋩
Off-Line
䋨Orange LED䋩
Error
䋨Red LED䋩
Input/Output connector DC POWER X1 (9 pins)
REMOTE X2 (37 pins)
COM1 X3 (9 pins)
COM2 X4 (9 pins)
STP-LINK X5 (8 pins)
OPTION X6 (12 pins)
Safety function Electromagnetic bearing failure detection
STP pump overheat detection
Motor driver overload detection
Power failure detection
STP pump overspeed detection
Control unit overheat detection
Other failure detection
