Edwards STP-iXA2205 Series User Manual

STP-iXA2205 Series Turbomolecular Pump
Nov. 10 16 Issue 1-h
TECHNICAL DATA
PAG
E
16
2
2.5 Power unit
Item Power unit iPS-1200
STP-iXA2205CP
*1
STP-iXA2205CPV
*1
STP-iXA2205CIP
*1
Input voltage ACV 200 to 240
Input power VA 1800 maximum
(with TMS unit)
1500 maximum
(with TMS unit)
Input frequency Hz 50/60 ± 2
Leakage current mA 2.0 maximum
Input phase Single phase
Main breaker specification A 10
Current Ampere Interrupting Capacity
(AIC)
A
1000
(240V AC 50/60Hz)
Mass kg 13
Pollution degree 2
Installation category
㸈
Panel indication LED POWER
*2
(Green LED)
Input/Output connector AC POWER X11 (3 pins)
DC OUTPUT X12 (9 pins)
HEATER X13
*3
(2 pins)
STP-LINK X14
*2
(8 pins)
*1
The STP-iXA2205CP(V)/CIP is equipped with the power unit iPS-1200.
*2
The STP-iXA2205CP(V)/CIP is not equipped with this connector.
*3
The STP-iXA2205CIP is not equipped with this connector.
