Integratethemeterwiththecontrolsystem
Table7-7OptionsforFrequencyOutputFaultAction
Code
ProLinkIIFieldCommunicatorFrequencyoutputbehavior
UpscaleUpscale
GoestoconguredUpscalevalue:
•Range:10Hzto15000Hz
•Default:15000Hz
DownscaleDownscale0Hz
InternalZeroIntrnlZero0Hz
None(default)None(default)Tracksdatafortheassignedprocessvariable
IfyousetmAOutputFaultActionorFrequencyOutputFaultActiontoNone,besuretosetDigital
CommunicationsFaultActiontoNone.Ifyoudonot,theoutputwillnotreportactualprocessdata,
andthismayresultinmeasurementerrororunintendedconsequencesforyourprocess.
IfyousetDigitalCommunicationsFaultActiontoNAN,youcannotsetmAOutputFaultActionor
FrequencyOutputFaultActiontoNone.Ifyoutrytodothis,thetransmitterwillnotacceptthe
conguration.
7.2.5ConfigureFrequencyOutputPowerSource
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→FO→POWER
ProLinkII
ProLink→Conguration→Frequency→PowerType
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→FrequencyOutput→FOSettings→PowerSource
UseFrequencyOutputPowerSourcetosettheoutputpowersourceforthefrequencyoutput.Thepower
congurationmustmatchthewiringforthefrequencyoutput.
Procedure
SetFrequencyOutputPowerSourceasdesired.
OptionDescription
InternalTheoutputispoweredbythetransmitter
ExternalTheoutputispoweredbyanexternalpower
source.
7.3Configurethediscreteoutput
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→DO
ProLinkII
ProLink→Conguration→DiscreteOutput
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→DiscreteOutput
Thediscreteoutputisusedtoreportspecicowmeterorprocessconditions.Thediscreteoutput
parameterscontrolwhichconditionisreportedandhowitisreported.
