Emerson Micro Motion 9739 MVD

Troubleshooting
Table10-19739MVDstatusLEDstates
LEDbehaviorAlarmconditionDescription
Solidgreen
NoalarmNormaloperation
FlashingyellowNoalarmZeroinprogress
Solidyellow
LowseverityalarmAlarmconditionthatwillnotcausemeasurement
error(outputscontinuetoreportprocessdata)
Solidred
HighseverityalarmAlarmconditionthatwillcausemeasurementerror
(outputsinfault)
10.2Statusalarms
Table10-2Statusalarmsandrecommendedactions
AlarmcodeDescriptionCauseRecommendedactions
A003
SensorfailureContinuityfailureof
drivecircuit,LPO,or
RPO,orLPO-RPO
mismatchwhen
driving.
•Checkthedrivegainandthepickoff
voltage.SeeSection10.25andSection
10.26.
•Checkthewiringbetweenthesensorand
transmitter.SeeSection10.10.
•Checkforelectricalshorts.SeeSection
10.27.
•Checksensortubes.
A004Temperaturesensor
failure
CombinationofA016
andA017
•Checkthesensorwiring.SeeSection
10.27.1.
•Checkthewiringbetweenthesensorand
transmitter.SeeSection10.10.
•Verifytemperaturecharacterization
parameters(TempCalFactor).
•Verifyprocessconditions.
•ContactMicroMotion.
A005Inputoverrange
Themeasuredow
hasexceededthe
maximumowrateof
thesensor(ΔTgreater
than200μs)
•Ifotheralarmsarepresent,resolvethose
alarmconditionsrst.Ifthecurrentalarm
persists,continuewiththerecommended
actions.
•Verifyprocessconditions.
•Checkforslugow.SeeSection10.24.
•Checkthedrivegainandthepickoff
voltage.SeeSection10.25andSection
10.26.
•Checkforelectricalshorts.SeeSection
10.27.
•Checksensortubes.
•ContactMicroMotion.
178
MicroMotion9739MVDTransmitters
