Densitycalibrationparameters(D1,D2,K1,K2,FD,DT,TC)
IfyoursensortagdoesnotshowaD1orD2value:
•ForD1,entertheDensAorD1valuefromthecalibrationcerticate.Thisvalueistheline-condition
densityofthelow-densitycalibrationuid.MicroMotionusesair.IfyoucannotndaDensAor
D1value,enter0.001g/cm
3
.
•ForD2,entertheDensBorD2valuefromthecalibrationcerticate.Thisvalueistheline-condition
densityofthehigh-densitycalibrationuid.
MicroMotionuseswater.IfyoucannotndaDensB
orD2value,enter0.998g/cm
3
.
IfyoursensortagdoesnotshowaK1orK2value:
•ForK1,entertherst5digitsofthedensitycalibrationfactor.InthesampletaginFigure5-1,this
valueisshownas12500.
•ForK2,enterthesecond5digitsofthedensitycalibrationfactor.InthesampletaginFigure5-1,
thisvalueisshownas14286.
IfyoursensordoesnotshowanFDvalue,contact
ow.support@emerson.com.
IfyoursensortagdoesnotshowaDTorTCvalue,enterthelast3digitsofthedensitycalibration
factor.InthesampletaginFigure5-1,thisvalueisshownas4.44.
Flowcalibrationparameters(FCF,FT)
Twoseparatevaluesareusedtodescribeowcalibration:a6-characterFCFvalueanda4-character
FTvalue.Bothvaluescontaindecimalpoints.Duringcharacterization,theseareenteredasasingle
10-characterstringthatincludestwodecimalpoints.ThisparameteriscalledeitherFlowcalorFCF.
IfyoursensortagshowstheFCFandtheFTvaluesseparately,concatenatethetwovaluestoform
thesingleparametervalue.
tExample:ConcatenatingFCFandFT
FCF=x.xxxx
FT=y.yy
Flowcalibrationparameter:x.xxxxy.yy
5.2Configuremassflowmeasurement
Display
OFF-LINEMAINT→OFF-LINECONFG→UNITS→MASS
ProLinkII
ProLink→Conguration→Flow
FieldCommunicatorCongure→ManualSetup→Measurements→Flow
Themassowmeasurementparameterscontrolhowmassowismeasuredandreported.
Themassowmeasurementparametersinclude:
•MassFlowMeasurementUnit
•FlowDamping
•MassFlowCutoff
64
MicroMotion9739MVDTransmitters
