Emerson Micro Motion 9739 MVD

Transmittercomponentsandinstallationwiring
B.2Transmitter-to-sensorwiring
RefertotheMicroMotion9739MVDTransmitters:InstallationManualforallsafetyand
detailedwiringinformationforthe9739MVDtransmitter.Youareresponsibleforfollowing
allsafetyandwiringinstructionsdocumentedinthetransmitterinstallationmanual,plus
anyadditionalsiterequirements.
Youcanwirethe9739MVDtransmittertothefollowingsensors:
•ELITE,H-Series,T-Series,andF-Series
•ModelDandModelDL
•ModelDT(withuser-suppliedmetaljunctionboxwithterminalblock)
Eachwireofthe9-wirecableisinsertedintothecorrespondingterminalatthesensorandtransmitter,
matchingbycolor(seeTableB-1).
TableB-1Sensorandtransmitterterminaldesignations
WirecolorSensorterminalTransmitterterminalFunction
BlackNoconnection0Drainwires
Brown11Drive+
Red22Drive−
Orange
33Temperature−
Yellow44Temperaturereturn
Green
55
Leftpickoff+
Blue66
Rightpickoff+
Violet
77
Temperature+
Gray
88
Rightpickoff−
White99
Leftpickoff−
B.3Powersupplyterminals
RefertotheMicroMotion9739MVDTransmitters:InstallationManualforallsafetyand
detailedwiringinformationforthe9739MVDtransmitter.Youareresponsibleforfollowing
allsafetyandwiringinstructionsdocumentedinthetransmitterinstallationmanual,plus
anyadditionalsiterequirements.
ConfigurationandUseManual
209
