Emerson Micro Motion 9739 MVD

Chapter8
Transmitteroperation
Topicscoveredinthischapter:
♦Recordtheprocessvariables
♦Viewprocessvariables
♦Viewtransmitterstatus
♦Viewandacknowledgestatusalarms
♦Startandstoptotalizersandinventories
♦Resetmassandvolumetotalizers
♦Resetmassandvolumeinventoriesusing
ProLinkII
8.1Recordtheprocessvariables
MicroMotionsuggeststhatyoumakearecordofspecicprocessvariablemeasurements,including
theacceptablerangeofmeasurements,undernormaloperatingconditions.Makingarecordofthe
variablemeasurementswillhelpyourecognizewhentheprocessvariablesareunusuallyhighorlow,
andmayhelpyoubetterdiagnoseandtroubleshootapplicationissues.
Procedure
Recordthefollowingprocessvariables,undernormaloperatingconditions:
Measurement
Processvariable
TypicalTypicalhighTypicallow
Flowrate
Density
Temperature
Tubefrequency
Pickoffvoltage
Drivegain
8.2Viewprocessvariables
Display
Scrolltothedesiredprocessvariable,orifAutoScrollisenabled,youcanwaituntiltheprocessvariableis
displayed.
ProLinkIIProLink→ProcessVariables
FieldCommunicatorOverview→Shortcuts→Variables→ProcessVariables
ConfigurationandUseManual
155
