Emerson Micro Motion 9739 MVD

Configureprocessmeasurement
Result:
•Ifthevolumeowratedropsbelow15liters/secondbutnotbelow10liters/second:
−TheprimarymAoutputwillreportzeroow.
−Thefrequencyoutputwillreporttheactualowrate,andtheactualowratewillbeused
inallinternalprocessing.
•Ifthevolumeowratedropsbelow10liters/second,bothoutputswillreportzeroow,and0will
beusedinallinternalprocessing.
5.4Configuregasstandardvolumeflowmeasurement
Display
OFF-LINEMAINT→OFF-LINECONFG→VOL→VOLTYPEGAS
ProLinkII
ProLink→Conguration→Flow→VolFlowType
FieldCommunicatorCongure→ManualSetup→Measurements→GasStandardVolume
Thegasstandardvolumeowmeasurementparameterscontrolhowgasstandardvolumeowis
measuredandreported.
Thegasstandardvolumeowmeasurementparametersinclude:
•VolumeFlowType
•StandardGasDensity
•GasStandardVolumeFlowMeasurementUnit
•GasStandardVolumeFlowCutoff
Restriction
Youcannotimplementbothliquidvolumeowandgasstandardvolumeow.Youmustchooseoneor
theother.
5.4.1ConfigureVolumeFlowTypeforgasapplications
Display
OFF-LINEMAINT→OFF-LINECONFG→VOL→VOLTYPEGAS
ProLinkII
ProLink→Conguration→Flow→VolFlowType→StdGasVolume
FieldCommunicatorCongure→ManualSetup→Measurements→GasStandardVolume→VolumeFlowType→GSV
VolumeFlowTypecontrolswhetherliquidorgasstandardvolumeowmeasurementwillbeimplemented.
Restriction
Ifyouareusingthepetroleummeasurementapplication,youmustsetVolumeFlowTypetoLiquid.Gas
standardvolumemeasurementisincompatiblewiththepetroleummeasurementapplication.
74
MicroMotion9739MVDTransmitters
