Configureprocessmeasurement
Restriction
Ifyouareusingtheconcentrationmeasurementapplication,youmustsetVolumeFlowTypetoLiquid.Gas
standardvolumemeasurementisincompatiblewiththeconcentrationmeasurementapplication.
Procedure
SetVolumeFlowTypetoGasStandardVolume.
5.4.2ConfigureStandardGasDensity
DisplayNotavailable
ProLinkII
ProLink→Conguration→Flow→StdGasDensity
FieldCommunicatorCongure→ManualSetup→Measurements→GasStandardVolume→GasDensity
StandardGasDensityisusedtoconvertthemeasuredowdatatoreference(standard)values.
Prerequisites
EnsurethatDensityMeasurementUnitissettotheunitsyouwilluseforStandardGasDensity.
Procedure
EntertheappropriateStandardGasDensityvalueforthegasyouaremeasuring.
Tip
ProLinkIIprovidesaGasWizardthatyoucanusetocalculatethestandarddensityofyourgas,ifyou
donotknowit.
5.4.3ConfigureGasStandardVolumeFlowMeasurementUnit
Display
OFF-LINEMAINT→OFF-LINECONFG→UNITS→VOL
ProLinkII
ProLink→Conguration→Flow→StdGasVolFlowUnits
FieldCommunicatorCongure→ManualSetup→Measurements→GasStandardVolume→GasVolFlowUnit
GasStandardVolumeFlowMeasurementUnitspeciestheunitwillbeusedforthegasstandardvolume
owrate.Theunitusedforthegasstandardvolumetotalandthegasstandardvolumeinventoryis
derivedfromthisunit.
Prerequisites
BeforeyoucongureGasStandardVolumeFlowMeasurementUnit,besurethatVolumeFlowTypeissettoGas
StandardVolume.
Procedure
SetGasStandardVolumeFlowMeasurementUnittothedesiredunit.
ThedefaultsettingforGasStandardVolumeFlowMeasurementUnitisSCFM(standardcubicfeetperminute).
