Quickstartwiththedisplay
2.2.2Defaultvaluesandranges
DefaultvaluesandrangesforthemostcommonlyusedparametersareprovidedinAppendixA.
2.3ConfiguretheprimarymAoutputtoreportmassflow
rateinauser-selectedmeasurementunit
Thisprocedureshowsyouhowtoperformthesetasksusingthedisplay.Forallotherconguration
tasks,includingotheroptionsforthemAoutput,seethecongurationsectionsofthismanual.
Note
Thisprocedureassumesthatyouarestartingfromthefactory-defaultconguration.
Procedure
1.Navigatetothecongurationmenu.
a.Atthetransmitterdisplay,activatetheScrollandSelectopticalswitchessimultaneouslyuntil
SEEALARMappearsonthedisplay.
b.ActivateScrollrepeatedlyuntilOFF-LINEMAINTappearsonthedisplay,thenactivateSelect.
c.ActivateScroll-Select-Scroll.
Thisoperatorsequenceisasafetyprecaution,designedtoprotectthetransmitterfrom
accidentalcongurationchangescausedbyunintentionalactivationoftheoff-linemenu.
Important
Ifyouhaveenabledadisplaypassword,theScroll-Select-Scrolloperatorsequenceisdisabled.
Youarerequiredtoenterapasswordbeforeyoucancontinue.Thedefaultpasswordis1234.
d.ActivateScrolluntilOFF-LINECONFGappearsonthedisplay,thenactivateSelect.
2.SetMassFlowMeasurementUnitasdesired.
a.WhenCONFIGUNITSappearsonthedisplay,activateSelect.
b.WhenUNITSMASSappearsonthedisplay,activateSelect.
c.ActivateScrolltoviewtheoptionsforMassFlowMeasurementUnit.Whenyouseethe
measurementunityouwanttouse,activateSelect.
IfSTORE/YES?ashesonthedisplay,
activateSelect.
d.ActivateScrolluntilUNITSEXITappearsonthedisplay,thenactivateSelect.
3.SetmAOutputProcessVariabletoMassFlowRate.
a.ActivateScrolluntilCONFIGIOappearsonthedisplay,thenactivateSelect.
b.WhenAO1appearsonthedisplay,activateSelect.
c.WhenAO1SRCappearsonthedisplay,activateSelect.
d.ActivateScrolltoviewtheoptionsformAOutputProcessVariableoptions.WhenyouseeMFLOW,
activateSelect.IfSTORE/YES?ashesonthedisplay,activateSelect.
4.SetLowerRangeValue(LRV).
