Integratethemeterwiththecontrolsystem
7.7Configureevents
DisplayNotavailable
ProLinkII
ProLink→Conguration→Events
FieldCommunicatorCongure→AlertSetup→DiscreteEvents
Aneventoccursifthereal-timevalueofauser-speciedprocessvariablemovespastauser-dened
setpoint.Eventsareusedtoprovidenoticationofprocesschangesortoperformspecictransmitter
actionsifaprocesschangeoccurs.
The
9739MVDtransmittersupportstwoeventmodels:
•Basiceventmodel
•Enhancedeventmodel
7.7.1Configureabasicevent
DisplayNotavailable
ProLinkII
ProLink→Conguration→Events
FieldCommunicatorCongure→AlertSetup→DiscreteEvents
A“basic”eventisusedtoprovidenoticationofprocesschanges.Abasiceventoccurs(isON)ifthe
real-timevalueofauser-speciedprocessvariablemovesabove(HI)orbelow(LO)auser-dened
setpoint.Youcandeneuptotwobasicevents.Eventstatuscanbequeriedviadigitalcommunications,
andadiscreteoutputcanbeconguredtoreporteventstatus.
Procedure
1.SelectEvent1orEvent2fromEventNumber.
2.SpecifyEventType.
HITheeventwilloccurifthevalueoftheassignedprocessvariable(x)is
greaterthanthesetpoint(SetpointA),endpointnotincluded.
x>A
LOTheeventwilloccurifthevalueoftheassignedprocessvariable(x)isless
thanthesetpoint(SetpointA),endpointnotincluded.
x<A
3.Assignaprocessvariabletotheevent.
