Chapter7
Integratethemeterwiththecontrol
system
Topicscoveredinthischapter:
♦CongurethemAoutputs
♦Congurethefrequencyoutput
♦Congurethediscreteoutput
♦Congurethediscreteinput
♦CongurethemAinput
♦Conguredigitalcommunications
♦Congureevents
♦Setuppollingforpressure
♦Setuppollingfortemperature
7.1ConfigurethemAoutputs
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→AO1
OFF-LINEMAINT→OFF-LINECONFG→IO→AO2
ProLinkII
ProLink→Conguration→AnalogOutput
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→mAOutput1
Congure→ManualSetup→Inputs/Outputs→mAOutput2
ThemAoutputisusedtoreportaprocessvariable.ThemAoutputparameterscontrolhowtheprocess
variableisreported.YourtransmitterhastwomAoutputs.
ThemAoutputparametersinclude:
•mAOutputProcessVariable
•LowerRangeValue(LRV)andUpperRangeValue(URV)
•AOCutoff
•AddedDamping
•AOFaultActionandAOFaultValue
