Emerson Micro Motion 9739 MVD

Configureprocessmeasurement
Table5-8EffectoftheFlowDirectionparameterandactualflowdirectiononflowtotals
Actualflowdirection
FlowDirectionsettingForwardZeroflowReverse
ForwardTotalsincreaseTotalsdonotchangeTotalsdonotchange
ReverseTotalsdonotchangeTotalsdonotchangeTotalsincrease
BidirectionalT otalsincreaseTotalsdonotchangeTotalsdecrease
AbsoluteValueTotalsincreaseTotalsdonotchangeTotalsincrease
NegateForwardT otalsdonotchangeTotalsdonotchangeTotalsincrease
NegateBidirectionalT otalsdecreaseTotalsdonotchangeTotalsincrease
5.6Configuredensitymeasurement
Display
OFF-LINEMAINT→OFF-LINECONFG→UNITS→DENS
ProLinkII
ProLink→Conguration→Density
FieldCommunicatorCongure→ManualSetup→Measurements→Density
Thedensitymeasurementparameterscontrolhowdensityismeasuredandreported.
Thedensitymeasurementparametersinclude:
•DensityMeasurementUnit
•Theslugowparameters:
−SlugHighLimit
−SlugLowLimit
−SlugDuration
5.6.1ConfigureDensityMeasurementUnit
Display
OFF-LINEMAINT→OFF-LINECONFG→UNITS→DENS
ProLinkII
ProLink→Conguration→Density→DensityUnits
FieldCommunicatorCongure→ManualSetup→Measurements→Density→DensityUnit
DensityMeasurementUnitspeciestheunitthatwillbeusedfordensitymeasurement.
Procedure
SetDensityMeasurementUnittothedesiredoption.
ThedefaultsettingforDensityMeasurementUnitisg/cm3(gramspercubiccentimeter).
OptionsforDensityMeasurementUnit
ThetransmitterprovidesastandardsetofunitsforDensityMeasurementUnit.Differentcommunications
toolsusedifferentlabels.
OptionsforDensityMeasurementUnitareshowninTable5-9.
84
MicroMotion9739MVDTransmitters
