Emerson Micro Motion 9739 MVD

Transmittercomponentsandinstallationwiring
FigureB-2Powersupplyterminals
E
B
C D
A
AExternalgroundterminal
BPowersupplyconduitopening
CL/L1forAC;+forDC
DN/L2forAC;–forDC
EPowergroundterminal
B.4Input/output(I/O)terminals
RefertotheMicroMotion9739MVDTransmitters:InstallationManualforallsafetyand
detailedwiringinformationforthe9739MVDtransmitter.Youareresponsibleforfollowing
allsafetyandwiringinstructionsdocumentedinthetransmitterinstallationmanual,plus
anyadditionalsiterequirements.
210MicroMotion9739MVDTransmitters
