Emerson Micro Motion 9739 MVD

Chapter3
QuickstartwithProLinkII
Topicscoveredinthischapter:
♦Applypower
♦Connectwith
ProLinkII
♦Congurationtipsandtricks
♦ConguretheprimarymAoutputtoreportmassowrateinauser-selected
measurementunit
♦Performalooptest
♦TrimmAoutputs
♦Zerotheowmeter
♦T estortunethesystemusingsensorsimulation
♦Backuptransmitterconguration
♦Enable/disableHARTsecurity
3.1Applypower
Prerequisites
Beforeyouapplypowertotheowmeter,closeandtightenallhousingcovers.
Topreventignitionofammableorcombustibleatmospheres,makesureallcoversare
tightlyclosed.Forhazardousareainstallations,applyingpowertotheunitwhilehousing
coversareremovedorloosecancauseanexplosion.
Procedure
Turnontheelectricalpoweratthepowersupply.
Theowmeterwillautomaticallyperformdiagnosticroutines.Fortransmitterswithadisplay,thestatus
LEDwillturngreenandbegintoashwhenthestartupdiagnosticsarecomplete.IfthestatusLED
exhibitsdifferentbehavior,analarmconditionispresent.
Postrequisites
Allowtheelectronicstowarmupforapproximately10minutesbeforerelyingonprocessmeasurements.
Althoughthesensorisreadytoreceiveprocessuidshortlyafterpower-up,theelectronicscantakeup
to10minutestowarmupcompletely.
3.2ConnectwithProLinkII
AconnectionfromProLinkIItoyourtransmitterallowsyoutoreadprocessdata,congurethe
transmitter,andperformmaintenanceandtroubleshootingtasks.
ConfigurationandUseManual
25
