Integratethemeterwiththecontrolsystem
Note
IfDiscreteOutputSourceissettoFaultandafaultoccurs,thediscreteoutputisalwaysON.Thesettingof
DiscreteOutputFaultActionisignored.
7.3.4ConfigureDiscreteOutputPowerSource
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→DO→POWER
ProLinkII
ProLink→Conguration→DiscreteOutput→PowerType
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→DiscreteOutput→PowerSource
UseDiscreteOutputPowerSourcetosettheoutputpowersourceforthediscreteoutput.Thepower
congurationmustmatchthewiringforthediscreteoutput.
Procedure
SetDiscreteOutputPowerSourceasdesired.
OptionDescription
InternalTheoutputispoweredbythetransmitter
ExternalTheoutputispoweredbyanexternalpower
source.
7.4Configurethediscreteinput
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→DI
ProLinkII
ProLink→Conguration→DiscreteInput
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→DiscreteInput
Thediscreteinputisusedtoinitiateoneormoretransmitteractionsfromaremoteinputdevice.
Thediscreteinputparametersinclude:
•DiscreteInputAction
•DiscreteInputPolarity
7.4.1ConfigureDiscreteInputAction
Display
OFF-LINEMAINT→OFF-LINECONFG→IO→DI→DIACT
ProLinkII
ProLink→Conguration→DiscreteInput→Assignment
FieldCommunicatorCongure→AlertSetup→DiscreteEvents→AssignDiscreteAction
DiscreteInputActioncontrolstheactionoractionsthatthetransmitterwillperformwhenthediscreteinput
transitionsfromOFFtoON.
134
MicroMotion9739MVDTransmitters
