Integratethemeterwiththecontrolsystem
4.Setavalueforthesetpoint(SetpointA).
5.(Optional)Congureadiscreteoutputtoswitchstatesaccordingtoeventstatus.
7.7.2Configureanenhancedevent
DisplayNotavailable
ProLinkII
ProLink→Conguration→DiscreteEvents
FieldCommunicatorCongure→AlertSetup→DiscreteEvents→DiscreteEvents1–5
An“enhanced”eventisusedtoperformspecictransmitteractionsiftheeventoccurs.Anenhanced
eventoccurs(isON)ifthereal-timevalueofauser-speciedprocessvariablemovesabove(HI)
orbelow(LO)auser-denedsetpoint,orinrange(IN)oroutofrange(OUT)withrespecttotwo
user-denedsetpoints.Youcandeneuptoveenhancedevents.Foreachenhancedevent,youcan
assignoneormoreactionsthatthetransmitterwillperformiftheenhancedeventoccurs.
Procedure
1.SelectEvent1,Event2,Event3,Event4,orEvent5fromEventName.
2.SpecifyEventType.
HITheeventwilloccurifthevalueoftheassignedprocessvariable(x)is
greaterthanthesetpoint(SetpointA),endpointnotincluded.
x>A
LOTheeventwilloccurifthevalueoftheassignedprocessvariable(x)isless
thanthesetpoint(SetpointA),endpointnotincluded.
x<A
INTheeventwilloccurifthevalueoftheassignedprocessvariable(x)is“in
range,”i.e.,betweenSetpointAandSetpointB,endpointsincluded.
A≤x≤B
OUTTheeventwilloccurifthevalueoftheassignedprocessvariable(x)is“outof
range,”i.e.,lessthanSetpointAorgreaterthanSetpointB,endpointsincluded.
x≤Aorx≥B
3.Assignaprocessvariabletotheevent.
4.Setvaluesfortherequiredsetpoints.
•ForHIorLOevents,setSetpointA.
•ForINorOUTevents,setSetpointAandSetpointB.
