Emerson Micro Motion 9739 MVD

Transmittercomponentsandinstallationwiring
FigureB-19739MVDtransmittercomponents
A
G
F
B
C
E
H
D
I
ARemovablehousingcover
BElectronicsmodule
CIntrinsicallysafesensorwiringterminals
DNon–intrinsically-safeoutputwiringterminals
EConduitopeningforsensorwiring
FConduitopeningforpowersupplywiring
GConduitopeningforoutputwiring
HHousingbase
IUserinterface:withorwithoutdisplayoptions
208MicroMotion9739MVDTransmitters
