Quickstartwiththedisplay
c.Atthetransmitter,activateSelect.
d.ScrolltoandselectSET20MA.
Dotstraversethedisplaywhiletheoutputisxed.
e.ReadthemAcurrentatthereceivingdeviceandcompareittothetransmitteroutput.
Thereadingsdonotneedtomatchexactly.Ifthevaluesareslightlydifferent,youcancorrect
thediscrepancybytrimmingtheoutput.
f.Atthetransmitter,activateSelect.
2.TestthesecondarymAoutput.
ChooseOFFLINEMAINT→SIM→AO2SIM,andrepeatthelooptestforthesecondarymAoutput.
3.Testthefrequencyoutput.
a.ChooseOFFLINEMAINT→SIM→FOSIM,andselectthefrequencyoutputvalue.
Thefrequencyoutputcanbesetto1,10,or15kHz.
Note
IftheWeights&Measuresapplicationisenabledonthetransmitter,itisnotpossibleto
performalooptestofthefrequencyoutput,evenwhenthetransmitterisunsecured.
Dotstraversethedisplaywhiletheoutputisxed.
b.Readthefrequencysignalatthereceivingdeviceandcompareittothetransmitteroutput.
c.Atthetransmitter,activateSelect.
4.Testthediscreteoutput.
a.ChooseOFFLINEMAINT→SIM→DOSIM,andselectSETON.
Dotstraversethedisplaywhiletheoutputisxed.
b.Verifythesignalstateatthereceivingdevice.
c.Atthetransmitter,activateSelect.
d.ScrolltoandselectSETOFF.
e.Verifythesignalstateatthereceivingdevice.
f.Atthetransmitter,activateSelect.
5.Readthediscreteinput.
a.Settheremoteinputdevicesothatthedesiredsignalissenttothetransmitter.
b.Atthetransmitter,chooseOFFLINEMAINT→SIM,andselectREADDI.
c.Verifythesignalstateatthetransmitter.
d.Repeattheprocedurefortheothersignalstate.
6.ReadthemAinput.
a.Settheremoteinputdevicesothatthedesiredcurrentissenttothetransmitter.
b.Atthetransmitter,chooseOFFLINEMAINT→SIM,andselectREADMAI.
