Configureprocessmeasurement
Restriction
Ifyouareusingthepetroleummeasurementapplication,youmustsetVolumeFlowTypetoLiquid.Gas
standardvolumemeasurementisincompatiblewiththepetroleummeasurementapplication.
Restriction
Ifyouareusingtheconcentrationmeasurementapplication,youmustsetVolumeFlowTypetoLiquid.Gas
standardvolumemeasurementisincompatiblewiththeconcentrationmeasurementapplication.
Procedure
SetVolumeFlowTypetoLiquid.
5.3.2ConfigureVolumeFlowMeasurementUnitforliquidapplications
Display
OFF-LINEMAINT→OFF-LINECONFG→UNITS→VOL
ProLinkII
ProLink→Conguration→Flow→VolFlowUnits
FieldCommunicatorCongure→ManualSetup→Measurements→Flow→VolumeFlowUnit
VolumeFlowMeasurementUnitspeciestheunitwillbeusedforthevolumeowrate.Theunitusedfor
thevolumetotalandthevolumeinventoryisderivedfromthisunit.
Prerequisites
BeforeyoucongureVolumeFlowMeasurementUnit,besurethatVolumeFlowTypeissettoLiquid.
Procedure
SetVolumeFlowMeasurementUnittothedesiredunit.
ThedefaultsettingforVolumeFlowMeasurementUnitisL/s(literspersecond).
Tip
Ifthemeasurementunityouwanttouseisnotavailable,youcandeneaspecialmeasurementunit.
OptionsforVolumeFlowMeasurementUnitforliquidapplications
ThetransmitterprovidesastandardsetofmeasurementunitsforVolumeFlowMeasurementUnit,plusone
user-denedspecialmeasurementunit.Differentcommunicationstoolusedifferentlabelsfortheunits.
OptionsforVolumeFlowMeasurementUnitareshowninT able5-2.
