Remote Output List (3 stations occupied, Default configuration *1)
Signal direction : Master station (PLC) → Remote device station (CC-Link board)
Bits indicated as “NA” are left for user. Use these free for SPEL+ program.
Address
Signal Name
Controller Bit No
RYn0
Start
*1
512
RYn1
SelProg1
*1
513
RYn2
SelProg2
*1
514
RYn3
SelProg4
*1
515
RYn4
Stop
*1
516
RYn5
Pause
*1
517
RYn6
Continue
*1
518
RYn7
Reset
*1
519
RYn8
SetMotorOn
*1
520
RYn9
SetMotorOff
*1
521
RYnA
Home
*1
522
RYnB
NA
523
RYnC
NA
524
RYnD
NA
525
RYnE
NA
526
RYnF
NA
527
RY(n+1)0
NA
528
:
:
RY(n+4)F
NA
591
RY(n+5)0
System reservation
592
RY(n+5)1
System reservation
593
RY(n+5)2
System reservation
594
RY(n+5)3
System reservation
595
RY(n+5)4
System reservation
596
RY(n+5)5
System reservation
597
RY(n+5)6
System reservation
598
RY(n+5)7
System reservation
599
RY(n+5)8
Initial data processing complete flag
*2
600
RY(n+5)9
Initial data configuration request flag
*2
601
RY(n+5)A
Error reset request flag
*2
602
RY(n+5)B
System reservation
603
RY(n+5)C
System reservation
604
RY(n+5)D
System reservation
605
RY(n+5)E
System reservation
606
RY(n+5)F
System reservation
607
*1 I/O assignment can be changed or invalid (NA). For details, refer to EPSON RC+
5.0 User’s Guide 10. Remote Control.
*2 For details, refer to the CC-Link flag operation section.
