Setup & Operation 7. LAN (Ethernet Communication) Port
RC180 Rev.17 45
7. LAN (Ethernet Communication) Port
- Refer to EPSON RC+ 5.0 User’s Guide 5.12.1 PC to Controller Communications
Command (Setup Menu) for other details for the development PC and Controller
connection.
- For Ethernet (TCP/IP) communication with robot application software, refer to EPSON
RC+ 5.0 Online Help or User’s Guide 12. TCP/IP Communications.
- Refer to Vision Guide 5.0 manual for other details of connection of the Controller and
CV1.
- This port is not used for EtherNet/IP. Use the port for fieldbusI/O board. For other
details, refer to Setup & Operation 12.3.7 EtherNet/IP.
7.1 About the LAN (Ethernet Communication) Port
Ethernet communication port supports 100BASE-TX / 10 BASE-T.
This port is used for three different purposes.
Connection with development PC
LAN (Ethernet communication) port is used for connection of the Controller and the
development PC.
Equivalent operation is available to connect between the Controller and the
development PC with the development PC connection port.
(Refer to Setup & Operation 5. Development PC Connection Port)
Connection with other Controller or PC
The LAN (Ethernet communication) port can be used as an Ethernet (TCP/IP)
communication port to communicate between multiple controllers from robot
application software.
Connection with CV1
The LAN (Ethernet communication) port is used for connection of the Controller and
CV1.

NOTE
