Setup & Operation 6. Memory Port
42 RC180 Rev.17
6.3.3 Load Data with EPSON RC+ 5.0
The following shows the procedure to read the data stored in the USB memory by EPSON
RC+ 5.0 and display the Controller status.
(1) Insert the USB memory into the PC with EPSON RC+ 5.0.
(2) Make sure that the following folder is indicated in the USB memory.
S_ serial number_data status was saved
→ Exmaple: S_12345_200608074410
(3) Copy the folder confirmed in procedure (2) to the “\EpsonRC50\Status” folder.
(4) Select the EPSON RC+ 5.0 menu-[Tools]-[Controller] to display the [Controller
Tools] dialog.
(5) Click the <Export Controller Status…> button.
(6) [Browse For Folder] dialog appears. Select the folder copied in procedure (3) and
click the <OK> button.
