Maintenance 4. Backup and Restore
RC180 Rev.17 131
(4) Click the <OK> button to display the dialog to select the restore data.
Robot name, serial #, calibration
This checkbox allows you to restore the robot name, robot serial number, Hofs data,
and CalPls data. Make sure that the correct Hofs data is restored. If the wrong
Hofs data is restored, the robot may move to wrong positions.
The default setting is unchecked.
Robot maintenance configuration
This checkbox allows you to restore the parts consumption data.
For details, refer to Appendix. Alarm.
The parts consumption management is available for the following Manipulator types:
G series (G1, G3, G6, G10, G20)
RS series (RS3, RS4)
The default setting is unchecked.
Project
This checkbox allows you to restore the files related to projects.
The default is unchecked.
When a project is restored, the values of Global Preserve variables are loaded.
For details about Global Preserve variable backup, refer to EPSON RC+ 5.0 User’s
Guide 5.10.10 Display Variables Command (Run Menu).
If the version of the Controller firmware is Ver.1.0.*.*, or the version of EPSON
RC+ 5.0 Ver.5.0.*, this dialog does not appear. Robot name, serial number, and
calibration data is always restored.
The project is not restored.
(5) Click the <OK> button to restore the system information.
Restore the system configuration saved using Backup Controller only for the same
system.
When different system information is restored, the following warning message
appears.
Click the <No> button (do not restore data) except for special situations such as
controller replacement.

NOTE

NOTE
