Maintenan
ce
5. Firmware Update
140
RC180 Rev.
17
(8)
Firmware and data file transfer star
ts.
It takes several
minutes to complete.
Do not unplug the
USB cable dur
ing transfer or t
urn OFF the Contr
oller or the
developm
ent PC.
(9)
The following dialog
appear
s
when transfer is compl
eted.
Click the <Next> but
ton
to reboot the C
ontroller.
(10)
The fol
lowing dialog
a
ppears
after
the Controller reboot
.
Click the
<Fini
sh> button.
The firmw
are upgrade is compl
eted.
Start EPSO
N RC+ 5.0 and re
store the Controll
er settings.
For detai
ls of restoring t
he operating sy
stem,
refer to
Maintenance 4. Backup
and Restore
.
NOTE
151
153
