Maintenance 6. Maintenance Parts Replacement Procedures
RC180 Rev.17 147
Battery
Installation
(1)
Place a new lithium battery in position
and secure it with the attached cable tie.
Position the
cable tie as show in the
photo.
If it is difficult to insert the lithium
battery to the Controller, adjust the cable
tie position.
(2)
Connect the relay connector.
(3)
Insert the lithium battery assembly into the
Controller.
Be sure to prevent the cable and the connector from being trapped.
Push the relay connector to
the left when inserting the lithium battery. If the
connecter is behind the lithium battery, the
lithium battery may not be inserted.
(4)
Mount the plate to the Controller with a screw.
(5)
Plug in
the power connector. Turn ON the Controller and make sure that the
Controller starts properly without any vibration or abnormal noise.

NOTE
