Setup & Operation 10. I/O Connector
60 RC180 Rev.17
Typical Input Circuit Application 2
1
Input No.0 to 7 common
2 Input No.0
3 Input No.1
4 Input No.2
5 Input No.3
6 Input No.4
7 Input
No.5
8 Input No.6
9 Input
No.7
I/O-1
(Same)
Omit
GND +DC
18 Input No.8 to 15 common
19 Input No.8
20 Input No.9
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
