Epson RC180 - Page 74

Setup & Operation 10. I/O Connector
62 RC180 Rev.17
Typical Output Circuit Application 2
10 Output No.0
I/O-
1
(Same)
Omit
+DC
29 Output No.8
30 Output No.9
11 Output No.1
12
Output No.2
13 Output No.3
14 Output No.4
15 Output No.5
27 Output No.
6
28 Output No.7
17 Output
No.0 to 7 common
(+DC)
Load
L
GND
L
33 Output No.8 to 15 common (+DC)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
