Epson RC180 User Manual

Setup & Operation 12. Option Units
78 RC180 Rev.17
Connector 2 Pin Assignments
Pin
No.
Signal Name
Pin
No.
Signal Name
Pin
No.
Signal Name
1 Input common No.80 to 87 18 Input common No.88 to 95 34
Not Used
2 Input No.80 19 Input No.88 35
Not Used
3
Input No.81
20
Input No.89
36
Not Used
4
Input No.82
21
Input No.90
37
Not Used
5
Input No.83
22
Input No.91
38
Not Used
6
Input No.84
23
Input No.92
39
Not Used
7
Input No.85
24
Input No.93
40
Not Used
8
Input No.86
25
Input No.94
41
Not Used
9 Input No.87 26 Input No.95 42
Not Used
10
Output No.80
27
Output No.86
43
Output No.91
11
Output No.81
28
Output No.87
44
Output No.92
12
Output No.82
29
Output No.88
45
Output No.93
13
Output No.83
30
Output No.89
46
Output No.94
14
Output No.84
31
Output No.90
47
Output No.95
15
Output No.85
32
Not Used
48
Not Used
16 Not Used 33
Output common No.88 to 95
49 Not Used
17
Output common No.80 to 87
50
Not Used
Connector Standard
I/O Connector (Controller side)
D-sub 50 male pin
Mounting style #4 - 40
* The I/O connector, I/O connector cable, terminal block, and I/O connector kit are offered as options.
