PRODUCT DESCRIPTION Printing Specifications 13
Confidential
Note* : Not supported in EAI.
Table 1-9. Print Mode for NX510 series (Monochrome)
Media Print Mode
Resolution
(H x V dpi)
Dot Size
(cps)
Bi-d
Micro
Weave
Border-
less
• Plain paper
• Premium Bright
White Paper (EAI)
• Premium Ink Jet
Plain papers (others)
Draft 3 /
Draft 4
360x360
Eco
(400cps)
ON OFF N/A
Normal 1 360x360
VSD1
(300cps)
ON OFF N/A
Fine 2 360x720
VSD2
(300cps)
ON ON N/A
Photo 1 720x720
VSD3
(285cps)
ON ON N/A
• Ultra Premium
Glossy Photo Paper
(EAI)
• Ultra Glossy Photo
Paper (others)
Best Photo 1440x720
VSD3
(285cps)
ON ON OK
• Photo Paper Glossy
(EAI)
• Glossy Photo Paper
(others)
• Premium Photo
Paper Glossy (EAI)
• Premium Glossy
Photo Paper (others)
Fine 1 360x720
VSD1
(300cps)
ON ON OK
Best Photo 1440x720
VSD3
(285cps)
ON ON OK
• Premium Photo
Paper Semi-Gloss
(EAI)
• Premium Semigloss
Photo Paper (other)
Draft 4 360x360
Eco
(400cps)
ON OFF N/A
Fine 1 360x720
VSD1
(300cps)
ON ON OK
Best Photo 1440x720
VSD3
(285cps)
ON ON OK
Photo Paper
*
(other)
Fine 1 360x720
VSD1
(300cps)
ON ON OK
Best Photo 1440x720
VSD3
(285cps)
ON ON OK
• Premium
Presentation Paper
Matte (EAI)
• Matte Paper Heavy-
weight (others)
Photo 2 720x720
VSD2
(285cps)
ON ON OK
Best Photo 1440x720
VSD3
(285cps)
ON ON OK
• Photo Quality Inkjet
Paper
*
(others)
Photo 2 720x720
VSD2
(285cps)
ON ON N/A
Best Photo 1440x720
VSD3
(285cps)
ON ON N/A
Envelope
Normal 1 360x360
VSD1
(300cps)
OFF OFF N/A
Fine 2 360x720
VSD2
(300cps)
OFF ON N/A
Table 1-9. Print Mode for NX510 series (Monochrome)
Media Print Mode
Resolution
(H x V dpi)
Dot Size
(cps)
Bi-d
Micro
Weave
Border-
less
