PRODUCT DESCRIPTION Interface 24
Confidential
The “Model Name” is replaced as shown in the following table.
1.5.2 Network Interface (NX510 series only)
NX510 series can be connected to the network via Wired or Wireless LAN connection.
(They can not be used simultaneously.) The following describes each Interface.
 Wired LAN
The following interface is equipped for the Wired LAN connection. The
communication mode can be selected from auto setting or fixed setting.
Note* : 10Base-T/100Base-TX Ethernet is supported. MDI/MDI-X is selected automatically.
Table 1-22. Device ID
When IEEE 1284.4 is Enabled When IEEE 1284.4 is Disabled
@EJL<SP>ID<CR><LF>
MFG:EPSON;
CMD:ESCPL2,BDC,D4,D4PX,ESCPR1;
MDL:Model Name;
CLS:PRINTER;
DES:EPSON<SP>Model Name;
CID:EpsonRGB;
@EJL<SP>ID<CR><LF>
MFG:EPSON;
CMD:ESCPL2,BDC;ESCPR1;
MDL:Model Name;
CLS:PRINTER;
DES:EPSON<SP>Model Name;
CID:EpsonRGB;
Table 1-23. Model Names Indicated in the Device ID
Destination North America Euro
Latin/Asia/
Pacific
China
NX510 series
Epson Stylus
NX510
Epson Stylus
SX510W
Epson Stylus
TX510W
---
SX410 series TBD TBD TBD ---
SX210 series
Epson Stylus
NX210
Epson Stylus
SX210
Epson Stylus
TX210
Epson ME
OFFICE 510
Table 1-24. Wired LAN
Item Content
Connector RJ-45 receptacle
*
: 1 port
Communication Speed For either 10Base-T or 100Base-TX, the Full Duplex or Half
Duplex can be selected.
Table 1-25. Combination of the Wired LAN communication mode settings
Setting of this printer Setting of the connected device
Auto Setting
Auto Setting (AUTO)
100BASE-TX Half Duplex
10BASE-T Half Duplex
100BASE-TX Full Duplex 100BASE-TX Full Duplex
100BASE-TX Half Duplex
Auto Setting (AUTO)
100BASE-TX Half Duplex
10BASE-T Full Duplex 10BASE-T Full Duplex
10BASE-T Half Duplex
Auto Setting (AUTO)
10BASE-T Half Duplex
