Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
PRODUCT DESCRIPTION Interface 23
Confidential
1.4.5 Safety Approvals (Safety standards/EMI)
USA UL60950-1
FCC Part15 Subpart B Class B
Canada CSA No.60950-1
CAN/CSA-CEI/IEC CISPR 22 Class B
Mexico NOM-019-SCFI-1998
Taiwan CNS13438 Class B
CNS14336 (IEC60950)
EU EN60950-1
EN55022 Class B
EN61000-3-2, EN61000-3-3
EN55024
Russia GOST-R (IEC60950, CISPR 22)
Korea K60950-1
KN22 Class B
KN61000-4-2/-3/-4/-5/-6/-11
Argentina IEC60950-1
Australia AS/NZS CISPR22 Class B
Singapore
*1
IEC60950-1
Hong Kong
*1
IEC60950-1
China
*1*2
GB8898
GB13837 Class B, GB17625.1
Note *1 : SX410 series is not compliant.
*2 : NX510 series is not compliant.
1.5 Interface
This printer has USB interface and memory card slots of the following specifications.
1.5.1 USB Interface
The mounted USB Interfaces differ between NX510/SX410/SX210 series. These
products are equipped with the USB Device Port to connect a computer. Moreover,
NX510/SX410 series are equipped with the USB Host Port to connect an external
device such as a DSC (Digital Still Camera), etc. The specifications of each USB port
are provided below.
Note* : The following devices can be connected to the USB Host port. (Not supported for
SX210 series)
• Devices compliant with DPS Version 1.0/1.1 (PictBridge)
• Devices compliant with Universal Serial Bus Mass Storage Class Bulk-Only Transport
Revision 1.0, and the Subclass code is one of the followings. (NX510 series only)
0x06 (SCSI transparent command set)
0x05 (SFF-8070i command set)
0x02 (SFF-8020i command set)
Table 1-21. USB Interface Specifications
Item USB Device port USB Host port
*
Compatible standards
• Universal Serial Bus
Specifications Revision 2.0
• Universal Serial Bus Device
Class Definition for Printing
Devices Version 1.1
• Universal Serial Bus Mass
Storage Class Bulk-Only
Transport Revision 1.0
• Universal Serial Bus
Specifications Revision
2.0
Transfer rate
NX510 series
480 Mbps (High Speed)
480 Mbps (MAX)
SX410 series
12 Mbps (MAX)
Data format
NRZI
Compatible connector
USB Series B USB Series A
Max. cable length
2 [m] or less
