PRODUCT DESCRIPTION Features 9
Confidential
1.1 Features
This section describes the features of these three models; NX510/SX410/SX210 series.
All the models are color inkjet printers with the scanner function.
 Common features
 Printer
• Printing from a computer or directly printing from a memory card.
• Maximum print resolution: 5760 (H) x 1440 (V) dpi
• Four independent ink cartridges is installed.
• Newly developed pigment ink is employed.
• Borderless printing on specified EPSON brand paper is available.
 Scanner
• Scanning from a computer
 Copy
• Stand alone copy using the scanning and printing functions
 Memory card slot
• Available as USB memory card slot for PC
 Differences of NX510/SX410/SX210 series
The differences between NX510/SX410/SX210 series are described below.
Note *1 : For the nozzle configuration, see Table 1-3.
*2 : For the details of the scanner specifications, see “ 1.3 Scanner Specifications ” (p.20).
*3 : For the details of the network interfaces, see “ 1.5.2 Network Interface (NX510 series
only) ” (p.24).
*4 : Supports both wired network and wireless network.
*5 : Supported devices for NX510 series and SX410 series differ. For the details, see
“ 1.5.1 USB Interface ” (p.23).
*6 : CF Card slot is not mounted on SX210 series. For the details of supported memory
cards, see “ 1.5.3 Memory Card Slots ” (p.26).
*7 : For the details of the functions, see “ 1.7.2 Scan Function (NX510/SX210 series
only) ” (p.36).
C H E C K
P O I N T
In this chapter, the product names are called as follows:
Notation Product name
NX510 series Epson Stylus NX510/NX515/SX510W/SX515W/TX550W
SX410 series Epson Stylus NX415/SX410/SX415/TX410/TX419
SX210 series
Epson Stylus NX215/SX210/SX215/TX210/TX213/
TX219/ME OFFICE 510
Table 1-1. Differences of NX510/SX410/SX210 series
Item NX510 series SX410 series SX210 series
Printhead
*1
O6-chips Turbo II D4-chips Turbo II D2-chips Turbo II
Color LCD
2.5-inch color a-TFT
stripe LCD
(with tilt function)
2.5-inch color a-TFT
stripe LCD
(with tilt function)
1.5-inch color LCD
(Cannot be tilted.)
Scanner resolution
*2
(Main scan x Sub scan)
2400 dpi x 2400 dpi 1200 dpi x 2400 dpi 1200 dpi x 2400 dpi
Network interfaces
*3
Available
*4
Not Available Not Available
USB Host Port
*5
Yes Yes No
Number of Memory
Card Slots
*6
2 2 1
Scan Function
*7
Yes No Yes
