Epson Stylus NX510 Service Manual

Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
PRODUCT DESCRIPTION Specification for Each Function 39
Confidential
1.7.3.5 Memory Card Direct Print Menu
The following describes the menu (settable items) in Memory Card Mode for NX510/
SX410 series. For SX210 series, only the Print Index Sheet function is available.
Note *1: 0 to 99 copies can be specified for each of the images. Up to 999 copies in total.
*2 : For SX210 series, press the [Index Sheet] button to print the index sheet. All images
in a memory card are included in the sheet.
*3 : The images are listed in ASCII descending order.
*4 : While performing the slide show, displaying number of copies, printing from an
external device or from a computer cannot be made.
1.7.3.6 Makes Prints from Index Sheet Function
 Print settings
Note *1 : NX510 series only. SX410/SX210 series do not support it.
*2 : NX510/SX410 series only. SX210 series do not support it.
 Rules on reading Index Sheet markings
The user can specify images to be printed and their print settings shown in Table
1-46 by putting marking on the Index Sheet. The printer reads the markings
according to the following rules.
Table 1-45. Memory Card Mode Menu
Menu Item Function
View and Print
Photos
*1,3
Prints the selected images.
Print All
Photos
*1,3
Prints all images in a memory card. Specified number of copies is applied
to the all images (the default is 1 copy). Specifying it for each of the
images independently also can be made in the preview screen.
Print by Date
*1
The date of the images are listed in the descending order with the number
of images by date. Selecting date from the list selects the images that has
the selected date information. Specified number of copies is applied to the
selected images (the default is 1 copy). Specifying it for each of the
images independently also can be made in the preview screen.
Print Index Sheet
(For SX210 series,
only this function is
available.
)
Print Index Sheet
*2
Prints an index sheet that prints images in a memory card in thumbnailed
form. The number of images to be included in the sheet can be selected
from the following four options.
“All image” (default), “Latest 30”, “Latest 60”, “Latest 90”
*3
Make Prints from Index Sheet
Scans the index sheet, and prints images according to markings written on
the sheet.
Slide Show
*4
Starts a slide show on the LCD. Images in a memory card is displayed one
by one in the order sorted by the printer. Printing one of the images can be
made from the paused screen.
Table 1-46. Print Settings
Item Print Index Sheet Makes Prints from Index Sheet
Number of copies ---
According to the marking on the index sheet.
Paper Type Plain paper
Paper Size A4, Letter
Layout ---
Quality Standard Standard
Expansion
*1
--- Standard
Date
YYYY.MM.DD
(2007.09.21)
*2
According to the marking on the index sheet.
BiDirectional On On
Print Index Sheet
Setting-Select
*2
According to the setting
made by the control panel.
---
Table 1-47. Rules on Reading Markings
Item Mark Description Remarks
Left edge
(one each)
Reference position for
reading markings.
An error occurs if these markings cannot be
read due to ink stain or any other cause.
Right edge
(one each)
Reference position for
reading markings.
Block code
(36 pcs.)
Sheet information
(memory card, page)
Image selection
(30 pcs. x 3)
Selects the image to be
printed.
An error occurs if no image selection
marking is read.
Paper type/size
(4 pcs.)
Selects the paper type/size. An error occurs if two or more markings are
read for one image.
