Epson Stylus NX510 Service Manual

Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
PRODUCT DESCRIPTION Specification for Each Function 34
Confidential
1.7 Specification for Each Function
1.7.1 Stand-alone Copy Function
1.7.1.1 Supported Paper and Copy Mode
Note *1 : Letter size is supported for EAI only.
*2 : Not supported for EAI.
*3 : NX510 series only.
Note * : Letter size is supported for EAI only.
For Latin, A4 and Letter are selectable on the panel.
1.7.1.2 Stand-alone Copy Menu
The following are the menu (settable items) for stand-alone copy.
Table 1-36. Supported Paper and Copy Mode for NX510/SX410 series
Paper Type Size
Print
Quality
Resolution
Dot
Size
Bi-D
Micro
Weave
Border-
less
Plain paper A4, Letter
*1
Draft
360x120 Eco ON OFF
NA
Standard
360x360 VSD1 ON OFF
NA
Best
720x720 VSD3 ON ON
NA
Matte paper A4, Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Paper
*2
4x6, 5x7,
A4,
Standard
1440x720 VSD3 ON ON
OK
Glossy
*3
4x6, 5x7
*2
,
A4, Letter
*
Standard
1440x720 VSD3 ON ON
OK
Prem. Glossy
4x6, 5x7,
A4, Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Ultra Glossy
4x6, 5x7,
A4, Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Table 1-37. Supported Paper and Copy Mode for SX210 series
Paper Type Size
Print
Quality
Resolution
Dot
Size
Bi-D
Micro
Weave
Border-
less
Plain paper
A4, Letter
*
Draft
360x120 Eco ON OFF
NA
Standard
360x360 VSD1 ON OFF
NA
Photo Paper 4x6 Standard
1440x720 VSD3 ON ON
OK
Table 1-38. Copy Menus for NX510/SX410 series
Menu Function
Number of copies Sets the number of copies within the range of 1 to 99.
Copy type Selects either color or monochrome.
Layout
Selects from the following two layouts:
• With Border (normal layout with 3mm margins)
• Borderless (no margins)
Print
setting
Paper type Selects paper type from the options shown in Table 1-36.
Paper size Selects paper size from the options shown in Table 1-36.
Quality Selects print quality from the options shown in Table 1-36.
Zoom
Selects Actual or Auto Fit Page.
Or reduction/enlargement ratio can be specified within the range
of 25% to 400%.
Density Selects from the nine density levels of -4 to +/-0 to +4.
Expansion
(for borderless print)
Selects the margins level (margins bleed off the edges of paper)
from the Standard (100%), Mid. (50%) or Min. (25%).
Table 1-39. Copy Settings for SX210 series
Setting Item Operation and Function
Number of copies Sets the number of copies within the range of 1 to 99.
Copy type Selects either color or monochrome.
Print
setting
Paper type
Selects paper type and size from the options shown in Table 1-37
using the Paper Type button.
Paper size
Quality Selects print quality from the options shown in Table 1-37.
Zoom
Selects Actual or Auto Fit Page.
Or reduction/enlargement ratio can be specified within the range
of 25% to 400%.
