Epson Stylus NX510 Service Manual

Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
PRODUCT DESCRIPTION Specification for Each Function 43
Confidential
1.7.4.4 Operating Specifications during Connecting DSC
1.7.5 Reprint/Restore Photos Function
(NX510 series only)
NX510 series offers the photo copy function. This function allows the user to copy
their silver halide film-based pictures. The printer scans the pictures automatically
detecting them as silver halide film-based picture, and makes a copy of them.
1.7.5.1 Supported Paper Type and Print Mode
Note *1 : Letter size is supported for EAI only.
*2 : The Photo Paper 5x7 size is not supported for EAI.
1.7.5.2 Reprint/Restore Photos Menu
Table 1-50. Operations during Connecting DSC
Operation Specifications
Connecting
DSC
(print start)
If an DSC is connected in Step 3-(1) of “ 1.7.4.3 General Operation Procedure
( p. 42 ) ”, the PictBridge logo is displayed on the LCD.
Canceling
printing
A print job can be canceled from the DSC.
The [Stop/Clear setting] button also cancels the print job.
After printing
is completed
When performing memory card direct print after printing from a DSC, the
USB cable connecting the DSC must be disconnected from the printer in
advance.
Exclusion
control
Print settings made on both the DSC and the printer can become impossible
settings for the printer due to unsupported combination of paper type, paper
size and layout. In such case, the print settings are automatically changed as
follows.
The settings made on the DSC are maintained. Any print setting items that are
not specified by the DSC are changed in accordance with the DSC settings.
When the paper type is changed, changed to Prem. Glossy, when the paper
size is changed, changed to 4x6 size. And when the layout is changed,
changed to Borderless layout.
Table 1-51. Paper Type and Print Mode
Paper Type Size Quality Resolution
Dot
size
Bi-D
Micro
Weave
Borde
rless
Matte paper A4, Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Photo Paper
4x6, 5x7
*2
,
A4, Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Prem. Glossy
4x6, 5x7, A4,
Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Ultra Glossy
4x6, 5x7, A4,
Letter
*1
Standard
1440x720 VSD3 ON ON
OK
Table 1-52. Reprint/Restore Photos Menu
Items Function
Number of copies Sets the number of copies within the range of 1 to 99.
Paper type Selects paper type from the options shown in Table 1-51.
Paper size Selects paper size from the options shown in Table 1-51.
Layout
Selects print layout from the following three options:
• Standard (normal layout with 3mm margins)
• Borderless (no margins)
Quality Fixed to “Standard“.
Expansion
Selects the margins level (margins bleed off the edges of paper)
from the Standard (100%), Mid. (50%) or Min. (25%).
Color restoration Selects from On or Off. The default is Off.
