PRODUCT DESCRIPTION Interface 26
Confidential
1.5.3 Memory Card Slots
Note: • Memory Stick/PRO, SD/MMC and xD-Picture Card shares the same slot.
• When cards are inserted in the two slots at once, the slot which will be accessed first is
determined according to the priority shown in the table.
• To select a card that has been inserted in a non-active slot, first remove the card in the
active slot.
• In memory card direct printing mode, the image files in the active slot are valid and
have assigned frame numbers. The number of images will not change if a card is
inserted in another nonselected slot.
• When the card inserted in the slot is accessed from the PC, only one drive is displayed
at a time as a removable disk
*
and only the card that is in the active slot can be
accessed via the removable disk. A card that has been inserted into a non-selected slot
cannot be accessed.
(This is for Windows. For Macintosh, the card in the active slot will be mounted on the
desktop.)
• Does not support 5V type of memory cards.
• When a memory card is being accessed, do not touch the memory card.
• For detailed information on the supported file system and formatting the memory card,
refer to
“ 1.7.3 Memory Card Direct Print Function ( p. 36 ) ”.
C A U T I O N
If you insert a Memory Stick DUO to the Memory Card Slot
without using the adapter, make sure to turn off the printer first,
then remove the card using tweezers.
Table 1-29. List of Supported Memory Card
Priority Slot Compatible memory card Standard Max. capacity Remarks
1
Memory Stick/
Memory Stick
PRO
Memory Stick “Memory Stick Standard” Format Specification Ver.1.43-00 compatible 128MB Includes versions with memory select function
MagicGate Memory Stick Copy protection function is not supported
MagicGate Memory Stick Duo An adapter should be used
Memory Stick PRO Memory Stick PRO Format Specifications-without security specifications
Ver.1.02-00 compatible
32GB
Copy protection function is not supported
Memory Stick Duo The Memory Stick Duo adapter should be used
Memory Stick Pro Duo The Memory Stick Duo adapter should be used.
Memory Stick micro The Memory Stick adapter for standard size should be used.
2
SD/MMC SD (Security Digital) SD Memory Card Specifications / PART1. Physical Layer Specification
Ver. 2.0 compatible
2GB
miniSD/microSD The SD adapter should be used
SDHC 32GB Speed Class is not supported
miniSDHC/microSDHC The SD adapter should be used
Speed Class is not supported
MultiMediaCard
MultiMediaCard Plus
MultiMediaCard Standard Ver. 4.2 compatible
4GB/32GB
Only MultiMediaCard Plus supports 32GB
3
xD-Picture card xD-Picture card xD-Picture Card Specification Ver.1.20 compatible
2GB
Type M/H supported
4
CF Type II
(No slot provided
for SX210 series)
Compact Flash CF+ and CompactFlash Specification Revision 4.1 compatible 32GB True-IDE compatible memory card only
Microdrive
