DISASSEMBLY/ASSEMBLY Disassembling the Scanner Unit 145
Confidential
 When installing the Scanner Motor Unit, align the positioning
holes (x2) of the Scanner Motor Unit with their positioning
tabs (x2) of the Lower Scanner Housing as shown in
Figure
4-125 .
 When routing the Scanner Motor cable, place the ferrite core
in the opening (1) after leading the Scanner Motor cable
through the opening (2) as shown in
Figure 4-125.
