Epson Stylus NX510 Service Manual

Epson Stylus NX510/515/SX510W/515W/TX550W/NX415/SX410/415/TX410/419/NX215/SX210/215/TX210/213/219/ME OFFICE 510 Revision A
ADJUSTMENT Using the Adjustment Program 174
Confidential
 Setting procedure
1. Connect the printer and a computer using a USB cable.
2. Start the Adjustment Program.
3. Select the “Initial Setting” from the menu. The initial setting screen appears.
4. Enter the last six digits of MAC address into the MAC address entry field, and
click the MAC Address input button.
(Enter the address again into the second entry field to confirm it.)
5. Select the network status sheet print menu on the printer’s control panel, and print
the sheet. Check the MAC address printed on the sheet to see if it is correct.
Figure 5-16. MAC Address Setting Screen
C A U T I O N
The MAC address required on the Adjustment Program is written
on the MAC address label on the
MB Upper Shield Plate . Make sure
to correctly enter the address.
Figure 5-15. MAC Address Label
Label, MAC Address
The last 6 digits of MAC Address
