Epson TM-P20II Reference Guide

119
10.4.6.1.4 Confirm IEEE802.1X Settings Page
If the Next button is pressed on the IEEE802.1X Top page or Wi-Fi Settings page, Web Config goes to the Confirm IEEE802.1X
Settings page.
10.4.6.1.4.1 Image
Figure 10-54 Confirm IEEE802.1X Settings Page
10.4.6.1.4.2 Input Information
The display items for entered information are changed from the top page or the Wi-Fi settings page.
Display items of input information is changed from top page or Wi-Fi settings page.
Table 10-123 Comparison of Display Items
 : display, - : hide
Disabled items on the top page are hidden.
Table 10-124 Description
Items
From Top Page
From Wi-Fi Settings Page
"SSID"
-

"Communication Mode"
-

"Security Level"
-

"IEEE802.1X(Wired LAN)"


"EAP Type"


"User ID"


"Password"


"Server ID"


"Anonymous Name"


"Encryption Strength"


Items
Description
Condition
"Confirm the following settings."
This message is shown at the top of the page,
followed by the setting items and their values.
-
"Communication will be shut down
temporarily to enable the new settings."
"You cannot access the network immediately
after the settings are changed."
"Depending on the changes, you may not be
able to connect to Web Config."
This message is shown at the bottom of the
page.
-
Input Information
Button
