EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Troubleshooting Fax Troubleshooting 189
Confidential
8-2. When the screen shown below appears, the storage of check results in
the USB memory is complete.
Figure 4-30. Check Results Storage - Work Procedure (2)
8-3. Press the [#] button and proceed to the End screen.
8-4. On the End screen, press the [Power] button to end “FAX Line
Measurement”.
Figure 4-31. Check Results Storage - Work Procedure (3)
 Sample stored check data
Figure 4-32. Sample stored check data
FAX Line Measurement
Save Result (USB)
Success!
Run:[#]
If you want to go to next step.
Push “Run”
FAX Line Measurement
Finish
Push “Power” to turn off.
No-Line
Line (OnHk)
Line (OffHk)
DT Lv
DT-On
DT-Off
BT Lv
BT-On
BT-Off
IR Freq
IR-On
IR-Off
EXT(OffHk)
: 0.0 - 0.0 [V]
: 48.0 - 48.0 [V]
: 6.0 - 6.0 [V]
: -20.0 [dBm]
: Continuous
: ------- [ms]
: -20.0 [dBm]
: 500 [ms]
: 500 [ms]
: 16.0 [Hz]
: 1000 [ms]
: 2000 [ms]
: 6.0 - 6.0 [V]

Epson WF-C5790 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 45, 000 pages
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Output Capacity	150 sheets
Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Ink Type	DURABrite Ultra pigment ink
Ink Cartridge Configuration	4 individual ink cartridges (Black, Cyan, Magenta, Yellow)
Print Technology	PrecisionCore
Print Speed (Black)	24 ppm (ISO)
Print Speed (Color)	24 ppm (ISO)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Mobile Printing	Apple AirPrint, Google Cloud Print
Scanner Type	Color flatbed
Fax Speed	33.6 Kbps
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Executive
